product description

PXH series gyratory crusher integrates mechanical, hydraulic, electrical, automation and intelligent control technologies, and is an intelligent coarse crushing equipment.

The gyratory crusher is mainly composed of the beam part, the upper, middle and lower frame parts, the moving cone part, the eccentric sleeve part, the transmission part and the hydraulic cylinder part. The eccentric sleeve drives the moving cone to swing in a circle, so as to continuously squeeze and crush the stones.

By adjusting the hydraulic cylinder at the bottom of the moving cone, the moving cone can move up and down to easily adjust the size of the discharge port and the particle size of the product. At the same time, the hydraulic cylinder also provides iron protection function. When an unbreakable object (such as iron block) enters the crushing cavity, the hydraulic cylinder can automatically drop the moving cone, thereby releasing the iron block and continuing to crush.

Product advantages

1. The crushing chamber can be suitable for various crushing application conditions and has good crushing performance.

2. Manganese steel wear parts are standard parts, and chrome alloy fixed cone lining plate and lower frame lining plate are optional parts.

3. The dust-proof seal is equipped with a positive pressure blower to prevent dust from entering the eccentric device and the drive device and prolong the life of the crusher bearing.

4. Balanced design is the design of mobile or fixed crushing operation, so that the impact force transmitted to the support frame of the crusher is small.

5. Beam bushings and seals can be easily replaced without removing the beam, which reduces manpower, time and equipment consumption and yield loss caused by downtime.

Zhongxin Heavy industry, a modern mining machinery manufacturer, is specialized in researching and developing, manufacturing and selling multi-cylinder hydraulic cone crusher. It is located in Boai Industrial District of Jiaozuo City in Henan Province, China, covering an area of more than 133,334 m2. One 20000m2 standard workshop has been built in the first phase with annual production capacity of 100 sets multi-cylinder hydraulic cone crusher and comprehensive annual output value of RMB 160,000,000.

Our company mainly manufactures equipment for stone production line, such as XHP multi-cylinder hydraulic cone crusher, jaw crusher, impact crusher, PSG Series Compound Cone Crusher, spring cone crusher, sand making machine, vibrating feeder, vibrating screen etc., which have been exported to more than 30 countries. With the advantages of super-high crushing efficiency and stability, XHP series multi-cylinder hydraulic cone crushers are highly appreciated by customers and widely applied to the crushing process of various ore or hard stone and cobblestone sand making and have achieved great effect.
