    Jiaozuo zhongxin spring stone cone crusher in factory stone crashing machine

    Ask Lasest Price
    Brand Name : zhongxin heavy industry
    Model Number : PY
    Price : USD 89999-129999
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10
    Delivery Time : 15-20day
    • Product Details
    • Company Profile

    Jiaozuo zhongxin spring stone cone crusher in factory stone crashing machine

    Spring cone crusher is suitable to crush all kinds of ores and rocks with medium hardness and above. It has features of reliable structure, efficiency, capacity,low operating cost,easy adjustment ,economical to use and so on.

    Jiaozuo zhongxin spring stone cone crusher in factory stone crashing machine


    Jiaozuo zhongxin spring stone cone crusher in factory stone crashing machine


    Spring system plays the role of overload protection, which will enable the exotic materials or steel piece to pass through the crushing chamber without any damage to the machine. It adopts grease seal to isolate dust and lubricants, therefore ensure its reliable operation. According to customer demand, respectively, using standard type, medium type and short head type for coarse crushing, medium crushing and fine crushing operation.


    Jiaozuo zhongxin spring stone cone crusher in factory stone crashing machine

    Processed Materials:Limestone, Granite, Gabbro, Basalt, River Stone, Coal Gangue, Quartz, Diabase,Iron Ore, Copper Ore, Zinc Ore, Manganese Ore, etc. (for Hard Stone).

    Jiaozuo zhongxin spring stone cone crusher in factory stone crashing machine

    The spring cone crushers by the change of the gap in the crushing cavity, and it has advantages:

    1,Strong crushing force; efficiency; crushing capacity;

    2,Low operation and maintenance cost, easy to adjust;


    Jiaozuo zhongxin spring stone cone crusher in factory stone crashing machine

    3,As spare parts selection and structural design is reasonable, the lifespan will be long;

    4,Reducing downtime;

    5,Different types of crushing chambers to satisfy different customers’ requirement.


    Jiaozuo zhongxin spring stone cone crusher in factory stone crashing machine

    Specification


    Type

    Dia. of Cone

    (mm)

    Adjusting Range

    of Discharge Opening

    (mm)

    Max Feed Size

    (mm)

    Capacity (t/h)Motor Power (kw)Weight (t)

    Overall Dimension

    (mm)

    PYB-60060012-256515-25305.51740×1225×1940
    PYD-6003-13365-23305.51740×1225×1940
    PYB-90090015-5011550-905510.181990×1640×2380
    PYZ-9005-206020-655510.191990×1640×2380
    PYD-9003-134015-505510.271990×1640×2380
    PYB-1200120020-50145110-20011024.72805×2300×2980
    PYZ-12008-2610050-150110252805×2300×2980
    PYD-12003-155018-10511025.62805×2300×2980
    PYB-1750175025-60215280-480155-16050.63610×2950×4185
    PYZ-175010-30185115-320155-160513610×2950×4185
    PYD-17505-158575-230155-16050.53610×2950×4185
    PYB-2200220030-60300590-1000260-280844790×3430×5080
    PYZ-220010-30235200-580260-280854790×3430×5080
    PYD-22005-16110120-370260-280854790×3430×4852

    Working Principle

    Jiaozuo zhongxin spring stone cone crusher in factory stone crashing machine

    Jiaozuo zhongxin spring stone cone crusher in factory stone crashing machineJiaozuo zhongxin spring stone cone crusher in factory stone crashing machineJiaozuo zhongxin spring stone cone crusher in factory stone crashing machineJiaozuo zhongxin spring stone cone crusher in factory stone crashing machine

    Jiaozuo zhongxin spring stone cone crusher in factory stone crashing machine
